LUXE3 - 3.0 METRE 240 VOLT BOOM GATE
OVERVIEW
The LUXE3 is exceptional value for money for a European manufactured boom gate. It comes complete with three metre boom, built in logic control board and 240 volt motor capable of up to 120 operations an hour. The perfect answer to controlling access to driveway entries. Use any form of access control like remote controls or stand alone proximity cards.
The LUXE3 is exceptional value for money for a European manufactured boom gate. It comes complete with three metre boom, built in logic control board and 240 volt motor capable of up to 120 operations an hour. The perfect answer to controlling access to driveway entries. Use any form of access control like remote controls or stand alone proximity cards.
PRICING
LUXE3 -
Boom gate motor, steel enclosure, boom and logic control board - BUY ONLINE
$2377.00
REMTAU -
4 channel 433mhz key ring style remote control. - BUY ONLINE
$66.00
TAUKEYPAD -
TAU wireless outdoor keypad - BUY ONLINE
$268.00
SPECIFICATION
Motor Voltage -
240 volts AC
Current Standby -
80mA
Current at use -
1.2A
Motor power -
180W
Maximum thrust -
160Nm
Opening time -
2.2 seconds
Maximum boom length-
3.0 metres
Duty cycle -
Maximum 120 cycles per hour.
Height -
1098mm
Width -
379mm
Depth -
233mm
Weight -
46 Kg
IP rating -
IP54
DOWNLOAD & MANUALS
BROCHURE -
INSTALL MANUAL -
TIPS N TRICKS -
OPTIONAL
Boom Support -
When you read most boom gate manuals carefully it is specified that booms over three metres in length should have a boom support. Boom supports come in various forms and can be used in conjunction with safety and security. The simplest form is drop down leg. Next you have a fixed boom support and finally boom support with locking magnetic lock for the boom.
Photocells -
A must have if you use automatic closing function is photocells. Photocells provide an extra level of safety to prevent boom gates from closing on vehicles or pedestrians. Boom gates can have a single set between the boom gate and the boom support or multiple sets if desired at various heights.
Mains Power Filter -
Boom gate automation like this usually is installed on commercial and industrial sites where you can be pretty certain the mains power is less than desirable. Dirty power can result in lack of reliability and increased service costs. Installing a good quality filter will not only guard against spikes and surges but clean up the power before it reaches your electronics.
When you read most boom gate manuals carefully it is specified that booms over three metres in length should have a boom support. Boom supports come in various forms and can be used in conjunction with safety and security. The simplest form is drop down leg. Next you have a fixed boom support and finally boom support with locking magnetic lock for the boom.
Photocells -
A must have if you use automatic closing function is photocells. Photocells provide an extra level of safety to prevent boom gates from closing on vehicles or pedestrians. Boom gates can have a single set between the boom gate and the boom support or multiple sets if desired at various heights.
Mains Power Filter -
Boom gate automation like this usually is installed on commercial and industrial sites where you can be pretty certain the mains power is less than desirable. Dirty power can result in lack of reliability and increased service costs. Installing a good quality filter will not only guard against spikes and surges but clean up the power before it reaches your electronics.
